More about the product
LCD panel( IPS screen) | |
Panel size | 7” (16:9) |
Native Resolution | 1024×600 |
Brightness (cd/m²) | 300 cd/m2 |
Contrast ratio | 1000:1 |
View angle | 85°/85°/85°/85° (R/L/U/D) |
Touch panel | |
Touchscreen Type | 10 points Projected capacitive touch |
Touch Interface | USB |
Signal Ports | |
VGA | 1×VGA |
USB | 1xUSB for touch |
HDMI | 1xHDMI |
DVI | 1XDVI |
OSD | |
OSD control | Brightness, contrast ratio, auto adjustment, H/V position, language select etc. |
Support OS | Windows XP , Windwows /7/8/10 , Linux, Mac OS X, Android, Raspberry Pi ect |
Power Supply | |
External Power Supply | AC 100 – 240V |
Working voltage | DC 12V |
Power consumption | ≤30W |
Operating Environment | |
Temperature Range | operating: -10 to 60°C, storage :-20 to 70°C |
Relative humidity | operating: 10% to 90% , storage :5% to 90% |
Packing Details | |
Packing detail | 1pcs/box 2pieces/carton |
Accessories | Power adapter, VGA cable,HDMI cable,DVI cable, USB touch cable, Stander optional |
Others | |
Warranty | 1 year warranty |
High-Resolution Displays
high-resolution screens that provide clear and detailed visuals, essential for monitoring complex processes and data. The clarity of the display ensures that operators can easily read and interpret information, reducing the risk of errors.
Product's Features
Industrial Touch Screen Monitors represent a significant advancement in the field of human-machine interaction, offering a robust and intuitive interface for monitoring and controlling industrial processes.
- Durability and Reliability: Industrial Touch Screen Monitors are constructed with rugged materials that can withstand the challenging conditions of industrial environments
- Touchscreen Interactivity: The touchscreen functionality allows for intuitive and efficient interaction with the system.
- Enhanced User Experience: The combination of a high-resolution display and touchscreen interactivity creates a user-friendly interface that improves the overall user experience.
Integration with Industrial Systems
Industrial Touch Screen Monitors are designed to integrate seamlessly with various industrial systems, including programmable logic controllers (PLCs), supervisory control and data acquisition (SCADA) systems, and human-machine interface (HMI) software. This integration allows for real-time monitoring and control of industrial processes.
Customization and Flexibility: These monitors offer a high degree of customization, allowing them to be tailored to specific industrial applications.
Applications:
> Automatic system: intelligent self-service terminal, intelligent retail terminal, O2O smart device, robot equipment;
> Public Places: subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums, museums, convention centers, ticket agencies, HR market, lottery centers;
> Business Organizations: supermarket, large-scale shopping malls, exclusive agency, chain shops, large-scale sales, star-rated hotels, restaurants, travel agencies, pharmacy;
> Financial Organizations: Banks, negotiable securities, funds, insurance companies, pawnshops;
> Non-profit Organizations: Telecommunications, post offices, hospital, schools;
> Real Estate Property: Apartments, villas, offices, commercial buildings, model rooms, property brokers;
> Entertainments: Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes, Internet bars, beauty shops, golf course;
Features and Advantages of LCD Display Touch Screen Monitor
Based on the product images provided, here are the key features and advantages of what would typically be included in a marine-grade waterproof LCD touch screen monitor:
Key Features:
Rugged Construction
IP65-rated waterproof and dustproof front panel (can withstand harsh marine environments)
Aluminum alloy design for durability and corrosion resistance
Tempered glass surface for impact resistance
Advanced Display Technology
High-definition LCD screen with LED backlight technology
Optional high brightness (for sunlight readability)
Anti-glare and anti-UV options available
Rich color reproduction and wide viewing angles
Touch Capabilities
10-point capacitive touch (multi-touch support)
Fast 5-second reaction time
Service life exceeding 50 million touches
Environmental Resistance
Wide operating temperature range (-10°C to 60°C, with customizable options)
Heat dissipation design for stable performance
Air circulation design to prevent overheating
Marine-Specific Adaptations
Waterproof front shell (critical for marine applications)
Anti-corrosion materials suitable for saltwater environments
Anti-interference design for electronic compatibility on vessels
